PRODUCTION METHODS

• The external façade aluminum profile raw material used in the system, AA 6063 T5 or AlMgSi 0,5 F 22 is produced in compliance with the relevant Turkish Standard 4922 and DIN norms (Din 17615) and TS 4922 and is painted in 180 different tones and wood pattern with electrostatic paint (min 60 microns).
• The wooden part on the internal side is made of imported extra – kiln dried, impregnated, fully massive timber.
• The internal section of the aluminum is made composite by snapping massive wood profile on U shaped canals and by gluing it with a special resin and then pressing it.
• The interlocked wooden and aluminum material constitutes an integrated whole.
• Since massive wood is an operating material, it is converted into laminated massive timber consisting of 2 or 3 parts at the production stage in order to prevent its operation.
• On the window and door system, which has specially designed press - EPDM washers, water leakage is prevented even without the external roving thanks to the special water discharge canals designed by ALKOSAN.
• A smooth and perfect surface is obtained on the wood thanks to the special grinding technique at the stage of production. Thanks to the imported paints made of the resin of wood, which do not clog the pores of the wooden surface, the wood allows your internal spaces breathe. (on – demand and special color choice in 18 different tons) The wooden double glazing moldings are assembled to each other with special adapters instead of nails or screws. By this way, the negative affects of nails and screws are eliminated. The wooden double glazing moldings are joined to produce a whole at the assembly area and placed in their seats in this form. By this way, the openings and deformations that may occur on the joint corners of double – glaze moldings are prevented at the stage of production.

ADVANTAGES OF ALUMINUM – WOOD ALUMINUM SNAP – ON SYSTEM

Wooden Internal Part

• ALKOSAN wood processing technology provides life – long warranty for the material.
• It does not include deleterious wood protection chemicals.
• It allows thinner profiles.
• It provides a comfortable and aesthetic use inside.

Aluminum External Part

• The used aluminum profile is strong against any kind of weather conditions.
• The aluminum shaping technology of ALKOSAN is applied taking into consideration the regional weather conditions.
• The external sections of the window and door systems are made of aluminum, which ensures great facilitation in routine maintenance.

TECHNICAL ADVANTAGES

• ALKOSAN wood aluminum window door systems provide the following technical advantages in use:
• Perfect response to the physical requirements of the building; sound, heat, static, frame (k) value: 1.3 - 1.7 W/m^2K
• Ideal venue air conditioning
• Zero condensation
• Coating details that can be appropriately resolved
• Constructive advantages, experienced technique
• Improved static properties allowing very thin profiles

DOOR AND WINDOW CHOICE

While choosing the door and window system, you must decide after performing a research on their surface maintenance, the resistance of the ingredients and their compliance with the building, whether it requires additional expenses after construction. The value of ALKOSAN windows is not calculated per part; the value they will provide to the building on which they will be installed and the life quality they provide are taken into consideration. In order to understand whether a system is economic for the building, in which it will be applied, ALKOSAN recommends you to review the following items:

• Architectural and stylistic contribution
• Contribution to the physical properties of the building (sound, heat, static)
• Ecological criteria (the convertibility of the material, environmental protection in its production)
• Ease of maintenance
• Durability, usable life and after-sales support
• Planning and design services
